Ultra-IBC Spill Pallet Twin Hard Top

1. Is the sump continuous or is it two separate compartments?

The 2025 kg sump is continuous.  In other words, a spill from one side will eventually make its way over to the other side.  There is no barrier to separate the two sides.  It is important to note that chemicals stored on the Ultra-Twin IBC Hard Top must be compatible.

2. What type of drain is used for these pallets?

The standard drain is a threaded hole in the sidewall with a 19mm polyethylene plug with NPT threads installed.

3. Is the Ultra-Twin IBC Hard Top waterproof?

No, the spill pallet is not completely waterproof.  It is more accurately described as weatherproof.  In other words, in standard weather conditions, your drums and/or containers should be protected and water gathering in the pallets is not a concern.  However, during very gusty conditions or very heavy rainfall, some water may get into the unit.  It is good practice to inspect the interior of the hard top after any severe weather.

4. Can I move the Ultra-Twin IBC Hard Top with IBCs on top?

No.  IBCs, tanks, totes, drums, and other items must be removed from the pallet surface prior to moving it.

5. What is the size of the grating that each IBC sits on?

Each side of the Ultra-Twin IBC Hard Top has a usable surface that is 1320mm x 1320mm  This surface comprised of two removable grates that are each 660mm x 1320mm.

6. How does the Ultra-Twin IBC Hard Top lock?

There is a single point where the top “rolltop” door meets with the bottom “swing-out” doors. Please note that each side of each compartment requires its own padlock.  In other words, a total of four (4) padlocks are required to secure one Ultra-Twin IBC Hard Top.

7. Is there a centre wall that separates the compartments in the Ultra-Twin IBC Hard Top or is it one large space for both IBCs?

There is a centre wall that separates the two compartments.

 8. Can the Ultra-Twin IBC Hard Top support an IBC that has pedestal posts for legs, or just flat bottom IBCs?

The pallet has an 3628 kg. per side capacity.  This is for uniformly distributed loads.  An IBC that is supported by pedestal post or feet focuses all of its weight on those feet.  If the dimensions of those feet are not large enough to properly displace the weight on the spill pallet’s grating, it could be an issue.  As a precaution, steel plates (at least 304mm x 304mm) can be used under the feet in order to more evenly distribute the weight over a greater area.

9. How long can I expect my UltraTech polyethylene (PE) spill containment product to last outdoors?

UltraTech’s general response to this question is at least ten (10) years. You can expect longer, but the actual life is dependent on several factors. UltraTech has been making outdoor spill containment products since 1993. We have a good sense of realistic life expectancy based on all those years of experience. UltraTech uses the highest-rated UV package in the resin formulation it uses to create the longest outdoor life available for a PE product

10. What are the factors that affect the life of a PE spill containment product outdoors?

UV and chemical exposures are the main environmental factors affecting the durability of outdoor polyethylene spill containment products. To ensure longevity, consider thickness, UV inhibitor content, and pigment colour, type, and concentration. UV exposure can cause PE to become brittle and fracture, but adding UV inhibitors and using darker or inorganic pigments can increase resistance to UV and prevent damage
